Dual Drive

What would you do if you had a million dollars?
I'll tell you what I would do.

Two overdrives at the same time.

The LEFT SIDE borrows roots from the classic "breaker" style circuit, and promptly branches out with some sweet new features. A unique transparency toggle gives you extended control over chord clarity and picking dynamics, while a high-headroom output stage gives you enough clean gain to push your amp's input over the proverbial edge.

The RIGHT SIDE is a high powered, hard clipping machine based on a very expensive pedal that dons a man-horse hybrid with a pension for archery. Unlike it's role model, this side of the Dual Drive feeds a carefully tuned two-band EQ section that's primed and ready to achieve optimal tonal balance in all scenarios.

Use the ORDER TOGGLE to flip-flop the two circuits to your liking. Make no mistake - Many, many righteous tones await your discovery when you toggle the order.

Left Side Controls:

DRIVE - Dial it up for more overdrive.
TONE - Removes excess treble.
LEVEL - Controls the output volume of the left side overdrive.
TOGGLE - Choose between two unique transparency modes.

Right Side Controls:

HIGH - Applies a shelf boost or cut to treble frequencies.
LOW - Applies a shelf boost or cut to bass frequencies.
LEVEL - Controls the output volume of the right side overdrive.
GAIN - Turning up the gain simultaneously removes clean signal and introduces a hard clipped overdrive.

Technical Specs:

• Soft Click Buffered Bypass
• 9v DC, 2.1mm center negative power. Does not accept batteries.
• Power Consumption: 28mA
• Enclosure Size: 4.7" x 3.75" x 1.75"

This pedal accepts 9VDC CENTER NEGATIVE power supplies ONLY.

Using the wrong power supply (i.e. higher than 9v, AC instead of DC, reverse polarity) will result in damage to the pedal.

POWER SUPPLY IS NOT INCLUDED.
